Remove a Storage Drive
The following table shows the location and numbering of the boot drives.
Callout
1
2
Remove a Storage Drive
Note -
2, Oracle Database Appliance X4-2, Oracle Database Appliance X5-2 or Oracle Database
Appliance X6 series. Refer to the preceding chapters in this document for information on
servicing those systems.
This section describes removing a storage drive from Oracle Database Appliance Version 1.
1. Identify the storage drive that you want to remove.
If a drive has failed, its amber Service Required LED will be lit. For information on drive status
LEDs, see
see "Storage and Boot Drive Locations" on page
Remove a storage drive.
2.
a. On the drive you plan to remove, push the storage drive release button to
open the latch [1].
120 Oracle Database Appliance Service Manual • June 2017
Drive Locations and Identification
Boot Drives at the back of server node 1. Location and identification of the server node 1 boot drives as
listed in Oracle ILOM:
■ /SYS/MB/RHDD1
■ /SYS/MB/RHDD0
Boot Drives at the back of server node 0. Location and identification of the server node 0 boot drives as
listed in Oracle ILOM:
■ /SYS/MB/RHDD1
■ /SYS/MB/RHDD0
Information in this appendix does NOT apply to Oracle Database Appliance X3-
"Storage and Boot Drive Status Indicators" on page 41. For specific drive locations,
118.
