Install Disk Midplane Module
There are four columns of standoffs, four in the left-most column and three in each of the
remaining columns.
e. Lift the disk midplane module up and out of the system [4].
f. Place the board on an antistatic mat.
Install Disk Midplane Module
Note -
2, Oracle Database Appliance X4-2, Oracle Database Appliance X5-2 or Oracle Database
Appliance X6 series. Refer to the preceding chapters in this document for information on
servicing those systems.
This section describes installing the disk midplane module from Oracle Database Appliance
Version 1.
1. Install the disk midplane module.
a. Move the front indicator module (FIM) cable connectors toward the rear of
the system so that the disk midplane module is not installed over them.
b. Lower the disk midplane module in the system chassis [1].
Position the disk midplane module against the disk drive cage, tilting the top
c.
slightly forward so that it fits over the top-most standoff on the left side and
then position board so that it fits over the remaining 12 standoffs, then push
downward on the board to engage the standoffs [2].
d. To secure the disk midplane module to the disk drive cage, install the
Phillips screw [3].
Reconnect the two FIM cable connectors to the receptacles on the disk
e.
midplane module [4].
180 Oracle Database Appliance Service Manual • June 2017
Information in this appendix does NOT apply to Oracle Database Appliance X3-
