Install Front Indicator Panel
Install Front Indicator Panel
Note -
2, Oracle Database Appliance X4-2, Oracle Database Appliance X5-2 or Oracle Database
Appliance X6 series. Refer to the preceding chapters in this document for information on
servicing those systems.
This section describes installing the front indicator panel in Oracle Database Appliance Version
1.
Use the Phillips screw to attach the new indicator panel to the ear bezel [1].
1.
Connect the ribbon cable to the indicator panel [2].
2.
Place the ear bezel on the chassis [3].
3.
4.
Fasten the four Phillips screws inside the drive bays [4].
5.
Fasten the three Phillips screws on the back of the ear bezel [5].
6.
Replace the disk drives in the drive bays [6].
188
Oracle Database Appliance Service Manual • June 2017
Information in this appendix does NOT apply to Oracle Database Appliance X3-
