Equipment damage. The HBA data cables are delicate. Ensure that they are
Caution -
removed and safely out of the way when servicing the motherboard.
Boot disk board cables.
■
See "Remove Boot Disk Backplane Cables" on page
3. Remove the following components from the server node.
Fan modules
■
"Remove a Fan Module" on page
Boot disk drives
■
"Remove a Boot Drive" on page
Boot disk drive backplane
■
"Remove Boot Disk Backplane" on page
Memory modules (DIMMS)
■
"Remove Faulty DIMMs" on page
PCIe riser and attached PCIe cards
■
"Remove PCIe Riser From Server Nodes" on page
CPUs
■
"Remove Processor (CPU)" on page
Internal primary HBA PCIe card
■
"Remove Primary HBA PCIe Card From Motherboard" on page
Battery
■
"Remove Battery" on page
Install Replaceable Components in Motherboard Assembly
Information in this appendix does NOT apply to Oracle Database Appliance X3-
Note -
2, Oracle Database Appliance X4-2, Oracle Database Appliance X5-2 or Oracle Database
Appliance X6 series. Refer to the preceding chapters in this document for information on
servicing those systems.
This section describes reinstalling the replaceable components removed when replacing the
motherboard in Oracle Database Appliance Version 1.
1. Attach an antistatic wrist strap.
See "Performing Electrostatic Discharge and Antistatic Prevention Measures" on page
Install Replaceable Components in Motherboard Assembly
126.
122.
169.
135.
144.
163.
157.
Appendix A • Servicing the Oracle Database Appliance Version 1
200.
153.
112.
