Oracle Database Appliance Version 1 Status Indicators

This section describes the status indicators for the Oracle Database Appliance Version 1.
"Server Node Status Indicators" on page 37
■
"Server Node Fan Indicators" on page 40
■
"Storage and Boot Drive Status Indicators" on page 41
■
"Power Supply Status Indicators" on page 41
■
"Rear Server Node Status Indicators" on page 42
■
"Server Node Internal LEDs" on page 44
■
"Ethernet Port Indicators" on page 45
■

Server Node Status Indicators

The following table lists and describes the general status indicators on the front and rear panel
of each Oracle Database Appliance Version 1 server node.
Indicator/LED: Color
AC power fault indicator: amber
Power supply status indicator:
green
Fan fail indicator: amber
DC power fail indicator: amber
SAS I/O Module status
indicators: green or amber
Reserved
Network port (reserved)
Host SAS port activity indicators
(x4 per port): green
Oracle Database Appliance Version 1 Status Indicators
State Meaning
■ On – Indicates an AC power fault.
■ Off – Normal operation.
■ On – The power supply is operating normally.
■ Off – The power supply is unplugged or turned off.
■ On – The fan is faulty.
■ Off – Normal operation.
■ On – The power supply is faulty.
■ Off – Normal operation.
■ OK – Lights green to indicate normal operation.
■ Service Required – Lights amber to indicate a fault with the I/O
module (top module is 0; bottom module is 1).
This port is reserved for Oracle Service.
This port is reserved for Oracle Service.
■ Random blinking – Indicates host SAS link activity.
■ Off – No link activity.
Chapter 1 • Overview of System Status Indicators and LEDs 37
