Install Power Distribution Board
2. Return the system to operation.
a. Install both server nodes into the system.
See
b. Install the middle section of the top cover.
Install and tighten the Phillips screws that secure the middle section of the top cover to the
system chassis.
c. Install both power supplies into the system.
See
d. If the system was installed in a rack, reinstall it into the rack.
See the Oracle Database Appliance Owner's Guide for instructions.
e. Reconnect the power cords to the system and power on the system.
See

Servicing the Disk Midplane Module (FRU)

Note -
2, Oracle Database Appliance X4-2, Oracle Database Appliance X5-2 or Oracle Database
Appliance X6 series. Refer to the preceding chapters in this document for information on
servicing those systems.
The Oracle Database Appliance Version 1 disk midplane interconnects the front disk drives to
the server nodes, the front indicator modules, and the power distribution board (PDB).
The disk midplane board is a FRU and can only be replaced by an Oracle-qualified service
technician.
Caution -
Electrostatic Discharge and Antistatic Prevention Measures" on page
components along their connector edges.
Caution -
installing the disk midplane board. Power down both server nodes (also called system
controllers) and disconnect the power cords from the system before performing these
procedures. For instructions, see
System" on page
176 Oracle Database Appliance Service Manual • June 2017
"Installing a Server Node Into the System Chassis" on page
"Install a Power Supply" on page
"Powering On Oracle Database Appliance Version 1" on page
Information in this appendix does NOT apply to Oracle Database Appliance X3-
Equipment damage. Follow antistatic precautions as described in
Equipment damage. Remove all power from the system before removing or
109.
130.
"Shutting Down a Server Node and Powering Off the
208.
210.
"Performing
112. Do not touch the
