Oracle Database Appliance X6-2-HA Manual page 170

Remove Boot Disk Backplane
1. Prepare the server node for service.
a. Attach an antistatic wrist strap.
See
Measures" on page
Remove the server node from the system.
b.
Power is removed from the server node when you remove it from the system. See
"Removing Server Nodes From the System Chassis" on page
c. Remove the server node top cover.
See
Unseat the boot disk drives.
2.
See "Remove a Boot Drive" on page
3. Remove the boot disk backplane.
a. Disconnect the power and data cables [1].
Remove the four Phillips screws that secure the boot disk backplane to the
b.
rear-mounted disk drives assembly and remove the backplane [2].
Place the boot disk backplane on an antistatic mat.
4.
170 Oracle Database Appliance Service Manual • June 2017
"Performing Electrostatic Discharge and Antistatic Prevention
112.
"Removing the Server Node Top Cover" on page 114.
122.
113.
