Replace a Storage Shelf HDD or SSD (CRU)
Note -
or SAS cable), you should wait before performing the next action to allow the system software
to fully process the event. This could take several minutes to complete.
Servicing Storage Shelf Components
Oracle Database Appliance X3-2/X4-2 (DE2-24P), Oracle Database Appliance X5-2 (DE2-
24C), and Oracle Database Appliance X6-2-HA (DE3-24C) storage shelf components can all be
replaced while the storage shelf is powered-on and running. They include:
"Replace a Storage Shelf HDD or SSD (CRU)" on page 58
■
"Adding Optional Oracle Database Appliance X6-2-HA Storage Shelf Drives
■
(CRU)" on page 62
"Replace a Storage Shelf Power Supply (CRU)" on page 66
■
"Replace a Storage Shelf I/O Module (CRU)" on page 70
■
Replace a Storage Shelf HDD or SSD (CRU)
Note -
SAS cable), you should wait before performing the next action to allow the system software to
fully process the event. This could take several minutes to complete.
1.
Locate the failed drive on the front of the storage shelf.
Look for the drive with its Service Required indicator and/or Ready-to-Remove indicator lit.
Caution -
replacement.
2.
Remove the drive:
For the DE3-24C, press the release button [1] to release the drive lever. For the DE2-24C,
■
slide the release latch as indicated by the debossed arrow to release the drive lever. Then,
rotate the lever open and, grasping the drive body, slide the drive out of the storage shelf [2].
58
Oracle Database Appliance Service Manual • June 2017
After a physical insertion or removal action of a storage shelf component (such as a disk
After a physical insertion or removal action of a storage component (such as a disk or
Equipment damage. Do not remove a drive unless you have an immediate
