Replace the Internal SAS HBA Cables
c. Connect the super capacitor cable to the super capacitor [2].
13. Return the server to operation.
a. Install the server top cover.
b. Return the server to the normal rack position.
Reconnect the power cords to the power supplies and power on the server.
c.
Use Oracle ILOM to clear any server PCIe card faults.
14.
You can use the Oracle ILOM web interface or the command-line interface (CLI) to manually
clear faults. For information on how to use the Oracle ILOM web interface or the CLI to clear
server faults, refer to the Oracle Integrated Lights Out Manager (ILOM) 3.2 Documentation
Library at http://www.oracle.com/goto/ilom/docs.
Replace the Internal SAS HBA Cables
These instructions describe replacing SAS cables for the factory installed Oracle Storage 12 Gb/
s SAS PCIe RAID HBA in an Oracle Database Appliance X6-2L system.
Caution -
To avoid personal injury or damage to the server, you must disconnect power cords before
servicing the cables.
Prepare the server for service.
1.
Refer to
additional details.
a. Power off the server and disconnect the power cords from the power
supplies.
b. Extend the server to the maintenance position.
c. Attach an antistatic wrist strap.
Remove the server top cover.
d.
Swivel the air baffle into the upright position to allow access to the SAS storage
2.
drive cables.
88 Oracle Database Appliance Service Manual • June 2017
The system supplies power to the cables even when the server is powered off.
"Preparing Oracle Database Appliance X6-2 Series for Service" on page 47 for
