Server Node Internal Leds - Oracle Database Appliance X6-2-HA Manual

Oracle Database Appliance Version 1 Status Indicators
Callout

Server Node Internal LEDs

The following section describes the internal LEDs for Oracle Database Appliance Version 1.
Each server node contains the following internal LEDs:
Note -
fault LEDs for up to 15 minutes after the server node is removed from a powered-on system
chassis. After approximately 15 minutes, the capacitor discharges enough so that it cannot light
the fault LEDs.
Fault Remind Power Good LED.
■
This green LED lights each time the Fault Remind button is pressed, if the capacitor has
enough of a charge to light the fault LEDs. This LED is located next to the Fault Remind
button.
For the location of Fault Remind button and the Fault Remind Power Good LED, see
"Remove Faulty DIMMs" on page
Memory DIMM Fault LEDs
■
Each DIMM slot has an adjacent DIMM fault LED. If a DIMM fails, the adjacent LED
lights when the Fault Remind button is pressed.
For the location of Fault Remind button and the DIMM fault LEDs, see
DIMMs" on page
CPU Fault LEDs
■
Both CPUs have an associated CPU fault LED. If a CPU fails, the associated LED lights
when the Fault Remind button is pressed.
For the location of CPU fault LEDs, see
Ethernet Port LEDs
■
Each server node has two host Ethernet ports (NET0 and NET1) and an SP network
management port (NET MGT). Each of these has two LEDs that indicate link activity and
port speed. See
44 Oracle Database Appliance Service Manual • June 2017
Indicator/LED: Color
A super capacitor (located on the motherboard) provides power to light the server node
135.
"Ethernet Port Indicators" on page
State Meaning
on system host or 2) the host is transitioning from the powered-
on state to the standby state on shutdown.
■ Steady on – The system is powered on and all host POST
tests passed. The system is one of the following states: 1) the
system host is ready to boot, or 2) the system host is booting the
operating system (OS), or 3) the system host is running the OS.
135.
"Remove Processor (CPU)" on page
45.
"Remove Faulty
163.
