Install Replaceable Components in Motherboard Assembly
2. Install the following components into the server node.
Fan modules
■
See
Boot disk drives
■
See
Memory modules (DIMMS)
■
See
PCIe riser and attached PCIe cards
■
See
CPUs
■
See
Internal primary HBA PCIe card
■
See
3. Reconnect and install the following cables.
Fan module power cables.
■
See
Internal PCIe card data cables.
■
See
Caution -
Boot disk backplane cables.
■
See
4. Return the server node to operation.
a. Install the server node top cover.
See
b. Install the server node into the system.
See
c. Reconnect all external data cables from the PCIe card(s) that are installed in
the PCIe riser.
Power on the server node.
d.
See
206 Oracle Database Appliance Service Manual • June 2017
"Install a Fan Module" on page
"Install a Boot Drive" on page
"Install DIMMs" on page
"Install PCIe Riser in Server Nodes" on page
"Install Processor (CPU)" on page
"Install Primary HBA PCIe Card in Motherboard" on page
"Servicing the Fan Power Cables (FRU)" on page
"Servicing the PCIe Card Cables (FRU)" on page
Equipment damage. The disk drive data cables are delicate. Handle them carefully.
"Servicing the Boot Disk Backplane Cables (FRU)" on page
"Installing the Server Node Top Cover" on page
"Installing a Server Node Into the System Chassis" on page
"Powering On Oracle Database Appliance Version 1" on page
127.
124.
139.
145.
166.
192.
207.
154.
190.
200.
208.
210.
