Remove Disk Midplane Module
5.
Loosen the two captive Phillips screws that secure the side-wall cover to the
chassis and remove the cover.
The side-wall cover is positioned under the middle section of the system top cover. Before you
can remove the side-wall cover, you must remove the middle section of the system top cover.
6.
Remove the power distribution board.
See
"Remove Power Distribution Board" on page
Remove the disk midplane module.
7.
178
Oracle Database Appliance Service Manual • June 2017
172.
