Install Disk Midplane Module
6. Reinstall both server nodes into the system.
See "Installing a Server Node Into the System Chassis" on page
7. Return the system to operation.
Install both power supplies into the system.
a.
See
b. If the system was installed in a rack, reinstall it into the rack.
See the Oracle Database Appliance Owner's Guide for instructions.
c. Reconnect the power cords to the system and power on the system.
See
Servicing the Disk Midplane Module HDD Cable
(FRU)
Note -
2, Oracle Database Appliance X4-2, Oracle Database Appliance X5-2 or Oracle Database
Appliance X6 series. Refer to the preceding chapters in this document for information on
servicing those systems.
The Oracle Database Appliance Version 1 HDD cable connects the power distribution board to
the disk midplane module.
The disk midplane module HDD cable is a FRU and can only be replaced by an Oracle-
qualified service technician.
Caution -
installing the disk midplane module HDD cable. Power down both server nodes (also called
system controllers) and disconnect the power cords from the system before performing
these procedures. For instructions, see
System" on page
The following topics are covered in this section:
"Remove Disk Midplane Module HDD Cable" on page 183
■
"Install Disk Midplane Module HDD Cable" on page 184
■
182 Oracle Database Appliance Service Manual • June 2017
"Install a Power Supply" on page
"Powering On Oracle Database Appliance Version 1" on page
Information in this appendix does NOT apply to Oracle Database Appliance X3-
Equipment damage. Remove all power from the system before removing or
109.
130.
"Shutting Down a Server Node and Powering Off the
208.
210.
