Notice that there are two sets of connectors on the motherboard. Be sure to connect the
cables to connector on the left in each set (looking at the connectors from the rear of the
server node).
Position the server node's front cover onto the server node and tighten
b.
the three green, captive Phillips screws that secure the server node's front
cover to the motherboard [1].
2. Return the server node to operation.
Install the server node top cover.
a.
See "Installing the Server Node Top Cover" on page
b. Install the server node into the system.
See "Installing a Server Node Into the System Chassis" on page
c. Power on the server node.
See "Powering On Oracle Database Appliance Version 1" on page
Servicing the SAS Expander Cable (FRU)
Information in this appendix does NOT apply to Oracle Database Appliance X3-
Note -
2, Oracle Database Appliance X4-2, Oracle Database Appliance X5-2 or Oracle Database
Appliance X6 series. Refer to the preceding chapters in this document for information on
servicing those systems.
The Oracle Database Appliance Version 1 SAS expander cable runs from a connector on the
front of the motherboard to a connector near the rear of the motherboard. See the following
sections for instructions.
The SAS expander cable is a FRU and can only be replaced by an Oracle-qualified service
technician.
The following topics are covered in this section:
"Remove SAS Expander Cable" on page 198
■
"Install SAS Expander Cable" on page 199
■
Install PCIe Card Cables for Secondary HBA PCIe Card
207.
Appendix A • Servicing the Oracle Database Appliance Version 1
208.
210.
197
