Analog Mixed Module, 12 Bit +/-10VDC Input 4 Channels and Output 2 Channels
Module Specifications
Module Characteristics

Channels

Module ID
Isolation:
User input to logic (optical) and to frame
ground
Group to group
Channel to channel
LED indicators
Backplane current consumption
Thermal derating
Configuration parameters
Diagnostics
External Power Supply
Recommended range
Current consumption at recommended range
12V operation range
Current consumption at 12V range
Input Characteristics
Input voltage:
Input Impedance
Accuracy at 25 degrees C*
Accuracy at 0 to 60 degrees C
Resolution:
Filter response
Update rate per module
Common mode voltage
Channel-to-channel crosstalk rejection
Output Characteristics
Output voltage
Load characteristics:
Resistive
Capacitive
Accuracy at 25 degrees C*
Accuracy at 0 to 60 degrees C
Resolution
Update rate per module
Channel-to-channel crosstalk rejection
Output default
* In the presence of severe RF interference, (IEC 1000-4-3, 10V/m), accuracy may be
degraded to +/-1%.
GFK-1504K Chapter 12 Analog Mixed I/O Modules
4 single-ended inputs, one group,
2 single-ended outputs, one group
FFFF9024
250VAC continuous; 1500VAC for 1 minute
Not applicable
None
FLD PWR LED indicates field power is present
OK LED indicates backplane power is present
5V output: 60mA maximum
None
Output default
Loss of User Side Power
+18 to +30VDC (including ripple)
160mA max.(including load current)
9.6 to 15VDC, 12VDC nominal (including ripple)
175mA max.(including load current)
+/-10VDC
125kOhms minimum
+/-0.3% typ. of full scale, +/-0.5% max. of full scale
+/-1% maximum of full scale
2.5mV = 8 counts
5.0ms
0.4ms
0 V
30dB minimum
+/-10.24VDC
5000 Ohms minimum
1.0µF maximum
+/- 0.3% typ. of full scale, +/- 0.5% max. of full scale
+/-1% maximum of full scale
5mV = 16 counts
0.3ms maximum
70dB minimum
Hold Last State (default), 0 (configurable)
12
IC200ALG432
12-17
