C
Catalog
Number
IC200ALG320
IC200ALG321
IC200ALG322
IC200ALG325
IC200ALG326
IC200ALG327
IC200ALG328
IC200ALG331
IC200ALG430
IC200ALG431
IC200ALG432
IC200ALG620
IC200ALG630
IC200MDD840
IC200MDD841
IC200MDD842
IC200MDD843
IC200MDD844
IC200MDD845
IC200MDD846
IC200MDD847
IC200MDD848
IC200MDD849
IC200MDD850
IC200MDD851
C-4
VersaMax® Modules, Power Supplies, and Carriers User's Manual – March 2003
Description
Analog Output Module, 12 Bit Current, 4 Channels
Analog Output Module, 12 Bit Voltage 0 to 10VDC 4 Channels
Analog Output Module, 12 Bit Voltage -10 to +10VDC 4 Channels
Analog Output Module, 13 Bit Voltage 8 Channels
Analog Output Module, 13 Bit Current 8 Channels
Analog Output Module, 13 Bit Voltage 12 Channels
Analog Output Module, 13 Bit Current 12 Channels
Analog Output Module, 16 Bit Voltage/Current, 1500VAC
Isolation, 4 Channels
Analog Mixed Module, 12 Bit Input Current 4 Channels and
Output Current 2 Channels
Analog Mixed Module, 12 Bit 0 to 10VDC Input 4 Channels and
Output 2 Channels
Analog Mixed Module, 12 Bit +/-10VDC Input 4 Channels and
Output 2 Channels
Analog Input Module, 16 Bit RTD, 4 Channels
Analog Input Module, 16 Bit Thermocouple, 7 Channels
Mixed Module, 24VDC Positive Logic Input 20 Points / Output
Relay 2.0 Amp 12 Points
Mixed Module, 24VDC Positive Logic Input 20 Points / Output 12
Point / (4) High Speed Counter, PWM, or Pulse Train
Configurable Points
Mixed Module, Output 24VDC Pos. Logic 0.5A Grouped w/ESCP
16 Points / Input 24VDC Pos/Neg Logic Grouped 16 Points
Mixed Module, 24VDC Positive Logic Input Grouped 10 Points /
Output Relay 2.0A per Point Grouped 6 Points
Mixed Module, Output 12/24VDC Pos. Logic 0.5A 16 Points /
Input 24 VDC Pos/Neg Logic Grouped 16 Points
Mixed Module, Output Relay 2.0A Isolated 8 Points / Input
24VDC Pos/Neg Logic Grouped 16 Points
Mixed Module, Output Relay 2.0A per Pt Isolated 8 Points / Input
120VAC Grouped 8 Points
Mixed Module, Output Relay 2.0A per Pt Isolated 8 Points / Input
240VAC Grouped 8 Points
Mixed Module, Output 120VAC 0.5A per Pt Isolated 8 Points /
Input 120VAC Grouped 8 Points
Mixed Module, Output Relay 2.0A per Pt Isolated 8 Points / Input
120VAC Isolated 8 Points
Mixed Module, Output Relay 2.0A per Pt Isolated 8 Points / Input
240VAC Isolated 4 Points
Mixed Module, Output 12/24VDC Pos. Grouped 16 Pts / Input
5/12VDC Pos/Neg Grp16 Pts
Backplane Current
Consumption in mA
5V
3.3V
50
50
50
50
50
50
50
10
115
50
60
60
125
125
125
125
375
30
130
100
190
70
270
300
300
125
295
275
115
GFK-1504K
