Module Specifications
Module Characteristics
Points
Module ID
Isolation:
User input to logic
(optical) or frame ground
Group to group
Point to point
LED indicators
Backplane current
consumption
External power supply
Thermal derating
Output Characteristics
Output voltage
Output voltage drop
Load current
Output leakage current
On response time
Off response time
Protection
Switching frequency
Relay type
Contact type
Contact life
GFK-1504K
Chapter 8 Discrete Output Modules
Output Module, Relay 2.0 Amp, Isolated Form A 16 Points
16 individually isolated Form A relay outputs
80408040
250VAC continuous; 1500VAC for 1 minute
250VAC continuous; 1500VAC for 1 minute
250VAC continuous; 1500VAC for 1 minute
One LED per point shows individual point ON/OFF state
OK LED indicates backplane power is present
5V output: 490mA maximum
0 to 125VDC, 5/24/125VDC nominal
0 to 265VAC (47 to 63Hz), 120/240VAC nominal
None
0 to 125VDC, 5/24/125VDC nominal
0 to 265VAC (47 to 63Hz), 120/240VAC nominal
0.3V maximum
10mA per point minimum
2.0A for 5 to 265VAC maximum (resistive)
2.0A for 5 to 30 VDC maximum (resistive)
0.2A for 31 to 125 VDC maximum (resistive)
Not applicable (open contact)
10ms maximum
10ms maximum
No internal fuses or snubbers
20 cycles per minute (inductive load)
Fixed coil, moving armature
Silver alloy
See appendix D
8
IC200MDL940
8-45
