GE VersaMax Manual page 260

Module Specifications
Module Characteristics
Points
Module ID
Isolation:
User input to logic (optical) and to
frame ground
Group to group
Point to point
LED indicators
Backplane current consumption
External power supply
Thermal derating
Configuration parameters
Input Characteristics
Input voltage
On state voltage
Off state voltage
On state current
Off state current
On response time
Off response time
Configurable filter time
Input impedance
Output Characteristics
Output voltage
Output voltage drop
Load current
Output leakage current
On response time
Off response time
Protection
GFK-1504K Chapter 9 Discrete Mixed Modules
Mixed Module, Output 12/24VDC Pos. Logic 0.5A 16 Points
/ Input 24 VDC Pos/Neg Logic Grouped 16 Points
1 group of 16 outputs
2 groups of 8 inputs
80088080
250VAC continuous; 1500VAC for 1 minute
250VAC continuous; 1500VAC for 1 minute
None
One LED per point shows individual point on/off state
FLD PWR LED indicates field power is present
OK LED indicates backplane power is present
5V output: 70mA maximum
+10.2 to +30VDC, +12/24VDC nominal
See diagram
Input response time
0 to +30VDC, +24VDC nominal
+15 to +30VDC
0 to +5VDC
2.0 to 5.5mA
0 to 0.5mA
0.5ms maximum
0 ms, 1.0ms (default), or 7.0ms
10kOhms maximum
+10.2 to +30VDC, +12/24VDC nominal
0.3V
0.5 Amp at 30VDC maximum (resistive)
2.0 Amps maximum for 100ms inrush
0.5mA at 30VDC maximum
0.2ms maximum
1.0ms maximum
No internal fuses
9
IC200MDD844
9-17
