Function Description - Endress+Hauser PROline Prosonic Flow 93 Function Manual

PROline Prosonic Flow 93 FOUNDATION Fieldbus
Endress+Hauser
BASIC FUNCTION
NOMINAL DIAMETER Use this function to select the nominal diameter of the pipe.
(6521)
Options:
OTHERS
DN 25/1"
DN 40/1½"
DN 50/2"
DN 80/3"
DN 100/4"
DN 150/6"
DN 200/8"
DN 250/10"
DN 300/12"
DN 400/16"
DN 450/18"
DN 500/20"
DN 600/24"
DN 700/28"
DN 750/30"
DN 800/32"
DN 900/36"
DN 1000/40"
DN 1200/48"
DN 1400/54"
DN 1500/60"
DN 1600/64"
DN 1800/72"
DN 2000/80"
Factory setting:
DN 80/3"
PIPE MATERIAL Use this function to select the pipe material.
(6522)
Options:
CARBON STEEL
CAST IRON
STAINLESS STEEL
SS ANSI 304
SS ANSI 316
SS ANSI 347
SS ANSI 410
SS ANSI 430
HASTELLOY C
PVC
PE
LDPE
HDPE
GRP
PVDF
PA
PP
PTFE
GLASS PYREX
ASBESTOS CEMENT
OTHERS
Factory setting:
STAINLESS STEEL

Function description

→
PROCESS PARAMETER (CH1...CH2)
7 Block BASIC FUNCTION
→
PIPE DATA
57
