3.3

Block output values

The Transducer Blocks make the following output values (process variables) available
to the downstream Analog Input function blocks:
• Transducer Block TRANSDUCER_CH1 (flow channel 1, base index 1200):
– Volume flow channel 1
– Sound velocity channel 1
– Flow velocity channel 1
– Signal strength channel 1
• Transducer Block TRANSDUCER_CH2 (flow channel 2, base index 1300):
– Volume flow channel 2
– Sound velocity channel 2
– Flow velocity channel 2
– Signal strength channel 2
• Transducer Block TRANSDUCER_CH1 and TRANSDUCER_CH2:
– Average volume flow
– Volume flow sum
– Volume flow difference
– Average sound velocity
– Average flow velocity
• Transducer Block TRANSDUCER_TOT (flow channel 2, base index 1550):
– Totalizer 1
– Totalizer 2
– Totalizer 3
• The Transducer Blocks TRANSDUCER_DISP (display, base index 1500),
TRANSDUCER_DIAG (diagnosis, base index 1600) and TRANSDUCER_SERV
(service, base index 1650) do not have any output values.
The CHANNEL parameter in the Analog Input function block, (see Page 171), is used to
assign the process variable which is read into and processed in the downstream Analog
Input function block.
The Transducer Block(s) in question must be in AUTO (automatic) mode for the process
variable to be processed correctly in the downstream Analog Input function block.
Transducer Base
Block: index
TRANSDUCER_CH1 1200
TRANSDUCER_CH2 1300
TRANSDUCER_CH1 1200
+
TRANSDUCER CH2 1300
TRANSDUCER_TOT 1550
3 Transducer Blocks (transmission blocks)
Operating
Process variable:
mode
AUTO Volume flow channel 1
Sound velocity channel 1
Flow velocity channel 1
Signal strength channel 1
AUTO Volume flow channel 2
Sound velocity channel 2
Flow velocity channel 2
Signal strength channel 2
AUTO Average volume flow
+
Volume flow sum
AUTO
Volume flow difference
Average sound velocity
Average flow velocity
AUTO Totalizer 1
Totalizer 2
Totalizer 3
Parameter
CHANNEL
(AI fct. block)
2
21
23
30
20
22
24
31
25
26
27
28
29
7
8
9
103
