Endress+Hauser PROline Prosonic Flow 93 Function Manual page 121

PROline Prosonic Flow 93 FOUNDATION Fieldbus
Endress+Hauser
"TRANSDUCER_CH1" and "TRANSDUCER_CH2" (E+H parameters) /
Parameter Write access
with operating
mode
(MODE_BLK)
Liquid Data - AUTO - OOS
Temperature
Liquid Data - read only
Unit Temperature
Liquid Data - AUTO - OOS
Sound Velocity
Liquid
Liquid Data - read only
Unit Sound
Velocity Liquid
Liquid Data - AUTO - OOS
Min. Sound
Velocity Liquid
3 Transducer Blocks (transmission blocks)
Base index 1200 and 1300
Description
Entry of the liquid temperature.
User input:
Fixed-point number -273.15...726.85 °C (0...1000 K)
Factory setting:
20


Note!
The unit used is displayed in the "Liquid Data - Unit Temperature"
parameter.
Displays the unit for the liquid temperature selected in the "Liquid
Data - Temperature" parameter.


Note!
The unit is selected in the "System Unit - Temperature" parameter,
see Page 111.
Entry of the sound velocity of the liquid.
Measuring the sound velocity of the liquid
Measurement can be carried out via:
• The local display ("Sensor" Quick Setup), see Page 19.
• The configuration and service software FieldTool.
User input:
Fixed-point number 400...3000
Factory setting:
1487


Note!
The unit used is displayed in the "Liquid Data - Unit Sound
Velocity Liquid" parameter.
Displays the unit for the liquid sound velocity selected in the
"Liquid Data - Sound Velocity Liquid" parameter.


Note!
The unit is selected in the "System Unit - Sound Velocity"
parameter, see Page 111.
Entry of the minimum sound velocity of the liquid.
User input:
Fixed-point number 400...3000
Factory setting:
800


Note!
The unit used is displayed in the "Liquid Data - Unit Min. Sound
Velocity Liquid" parameter.
121
