PROline Prosonic Flow 93 FOUNDATION Fieldbus
Endress+Hauser
Base index: AI 1 = 350, AI 2 = 390, AI 3 = 430, AI 4 = 470, AI 5 = 510, AI 6 = 550, AI 7 = 590, AI 8 = 630
Parameter Write access
with operating
mode
(MODE_BLK)
SIMULATE AUTO - MAN -
OOS
ST_REV read only
STATUS_ OOS
OPTS
STRATEGY AUTO - MAN -
OOS
Analog Input function block /
Description
Simulation of the input value and input status. Since this value runs
through the entire algorithm, the behaviour of the Analog Input
function block can be checked.
Factory setting:
Simulation Disabled (simulation not active)


Note!
• The BLOCK_ERR parameter of the Resource Block indicates
whether simulation is possible, (see Page 92).
• The BLOCK_ERR parameter of the Analog Input function block
indicates whether simulation is active, (see Page 170).
• The simulation mode is enabled by means of jumpers on the I/O
board, (see Operating Instructions for PROline Prosonic Flow 93
FOUNDATION Fieldbus, BA078D/06/en).
Displays the revision status of the static data.


Note!
The revision status parameter is incremented on each modification
of static data.
Specifies the options for status processing and processing of the
output value OUT.
The following options are supported by the Analog Input function
block:
Options:
Uncertain if MAN mode:
The status of the output value OUT changes to UNCERTAIN if the
operating mode is set to "MAN".
Propagate Fault Forward:
Fault is forwarded on. The status of the corresponding Transducer
Block is relayed to the downstream function blocks via the
BKCAL_OUT parameter.
Factory setting:
No options active
Parameter for grouping and thus faster evaluation of blocks.
Grouping is carried out by entering the same numerical value in the
STRATEGY parameter of each individual block.
Factory setting:
0


Note!
These data are neither checked nor processed by the Analog Input
function block.
4 Analog Input function block
