PROline Prosonic Flow 93 FOUNDATION Fieldbus
Endress+Hauser
"TRANSDUCER_TOT" (E+H parameters) / base index 1550
Parameter Write access
with operating
mode
(MODE_BLK)
Totalizer 3 - AUTO - OOS
System Value
Totalizer 3 - AUTO - OOS
System Unit
3 Transducer Blocks (transmission blocks)
Description
Use this parameter to view the total for the totalizer's measured
variable aggregated since measuring commenced. This value can
be positive or negative, depending on the setting selected in the
"Totalizer 3 - Mode" parameter (see Page 154) and the direction of
flow.


Note!
• The effect of the setting in the "Totalizer 3 - Mode" parameter (see
Page 154) is as follows:
– If the setting is "BALANCE", the totalizer balances flow in the
positive and negative directions.
– If the setting is "FORWARD", the totalizer registers only flow in
the positive direction.
– If the setting is "REVERSE", the totalizer registers only flow in
the negative direction.
• The totalizers' response to faults is defined in the "Totalizer
Handling - Failsafe All" parameter, (see Page 155).
Use this parameter to define the unit for the measured variable
selected for the totalizer.
Options:
Metric:
→
Cubic centimetre cm³
→
Cubic decimetre dm³
→
Cubic metre m³
→
Millilitre ml
→
Litre l
→
Hectolitre hl
→
Megalitre Ml MEGA
US:
→
Cubic centimetre cc
→
Acre foot af
→
Cubic foot ft³
→
Fluid ounce oz f
→
Gallon US gal
→
Million gallon US Mgal
Barrel (normal fluids: 31.5 gal/bbl)
→
Barrel (beer: 31.0 gal/bbl)
Barrel (petrochemicals: 42.0 gal/bbl)
Barrel (filling tanks: 55.0 gal/bbl)
Imperial:
→
Gallon imp. gal
→
Mega gallon imp. Mgal
→
Barrel (beer: 36.0 gal/bbl)
Barrel (petrochemicals: 34.97 gal/bbl)
Factory setting:
Depends on country (dm³...m³ or US gal...US Mgal), corresponds
to the totalizer unit factory setting, (see Page 76 ff.).


Note!
The unit selected here has no effect on the desired volume unit
which should be transmitted via the FF interface. This setting is
made separately via the appropriate AI Block in the XD_SCALE
parameter group, (see Page 180).
→
US bbl NORM.FL.
US bbl BEER
→
US bbl PETROCH.
→
US bbl TANK
imp. bbl BEER
→
imp. bbl PETROCH.
