5 Block USER INTERFACE
36
USER INTERFACE
Contd:


ASSIGN
Multiplex mode is suspended as soon as a fault/notice message is generated.
(2420)
The appropriate error message appears on the display:
• Fault message (identified by a lightning icon): Multiplex mode is resumed as
• Notice message (identified by an exclamation mark): Multiplex mode is
If a channel is not visible, it does not appear in the options. The channels can
be displayed or hidden by means of the MEASUREMENT (6880) function.
100% VALUE


(2421)
This function is not available unless one of the following options was selected
in the ASSIGN (2420) function:
• VOLUME FLOW % CH1
• VOLUME FLOW % CH2
• CALCULATED VOLUME FLOW %
• VOLUME FLOW BARGRAPH % CH1
• VOLUME FLOW BARGRAPH % CH2
• CALCULATED VOLUME FLOW BARGRAPH %
Use this function to define the flow value to be shown on the display as the
100% value.
User input:
5-digit floating-point number
Factory setting:
Depends on country, [value] / [dm³...m³ or US-gal...US-Mgal]
FORMAT


(2422)
This function is not available unless a numerical option was selected in the
ASSIGN (2420) function.
Use this function to define the maximum number of places after the decimal
point for the second value displayed in the additional line.
Options:
XXXXX. - XXXX.X - XXX.XX - XX.XXX -X.XXXX
Factory setting:
X.XXXX


• Note that this setting only affects the reading as it appears on the display, it
• The places after the decimal point as computed by the measuring device
PROline Prosonic Flow 93 FOUNDATION Fieldbus

Function description

→
ADDITIONAL LINE
Note!
soon as the fault is no longer active.
resumed as soon as the notice message is no longer active.
Note!
Note!
Note!
has no influence on the accuracy of the system's calculations.
cannot always be displayed, depending on this setting and the engineering
unit. In these instances an arrow appears on the display between the
measured value and the engineering unit, (e.g. 1.2
the measuring system is computing with more decimal places than can be
shown on the display.
→
MULTIPLEX
→
m³/h), indicating that
