PROline Prosonic Flow 93 FOUNDATION Fieldbus
Endress+Hauser
"TRANSDUCER_CH1" and "TRANSDUCER_CH2" (E+H parameters) /
Parameter
Write access
with operating
mode
(MODE_BLK)
Sensor Param. -
read only
Wire Length
Sensor Param. -
read only
Unit Wire Length
Sensor Param. -
read only
Sensor Distance
Sensor Param. -
read only
Unit Sensor
Distance
Sensor Param. -
read only
ARC Length
3 Transducer Blocks (transmission blocks)
Base index 1200 and 1300
Description

Note!
This parameter is not active unless "CLAMP ON" was selected in
the "Sensor Param. - Measurement" parameter and the number of
traverses in the "Sensor Param. - Sensor Configuration"
parameter is 1 or 3.
Displays the wire length for mounting the sensors at the correct
distance.
Display:
Max. 5-digit number

Note!
The unit used is displayed in the "Sensor Param. - Unit Wire
Length" parameter.
Displays the unit used for the display in the "Sensor Param. - Wire
Length" parameter.

Note!
The unit is selected in the "System Unit - Length" parameter, see
Page 112.
Displays the distance between sensor 1 and sensor 2 as a length
measurement.
Display:
Max. 5-digit number

Note!
The unit used is displayed in the "Sensor Param. - Unit Sensor
Distance" parameter.
Displays the unit used for the display in the "Sensor Param. -
Sensor Distance" parameter.

Note!
The unit is selected in the "System Unit - Length" parameter, see
Page 112.

Note!
This parameter is not active unless "INSERTION" was selected in
the "Sensor Param. - Measurement" parameter and "DUAL PATH"
was selected in the "Sensor Param. - Sensor Configuration"
parameter.
Displays the arc length on the pipe.
Display:
Max. 5-digit number

Note!
The unit used is displayed in the "Sensor Param. - Unit ARC
Length" parameter.
125
