PROline Prosonic Flow 93 FOUNDATION Fieldbus
Endress+Hauser
3.11 E+H parameters: Transducer Block
"TRANSDUCER_DISP" (display)
The following table lists all the E+H-specific parameters of the Transducer Block
"TRANSDUCER_DISP" (display). The conditions which have to be met before changing
these parameters are provided on Page 105.
"TRANSDUCER_DISP" (E+H parameters) / base index 1500
Parameter Write access
with operating
mode
(MODE_BLK)


Note!
A description of the FOUNDATION Fieldbus parameters of this block is provided on Page 106.
Un-/Locking - AUTO - OOS
Access Code
Un-/Locking - read only
Access Status
Un-/Locking - AUTO - OOS
Define Private
Code
3 Transducer Blocks (transmission blocks)
Description
All data of the measuring system are protected against inadvertent
change. Only when the code has been entered in this parameter
can the manufacturer-specific parameters (E+H parameters) be
programmed and the device configuration modified.
You can enable programming by entering:
• Code 93 (factory setting)
• Personal code (see Page 129)
User input:
Max. 4-digit number (0...9999)


Note!
• If write protection is enabled, access to the manufacturer-specific
parameters is blocked even if the right code is entered. (More
detailed information on write protection is provided in the
Operating Instructions for PROline Prosonic Flow 93
FOUNDATION Fieldbus, BA078D/06/en, Section 5.4).
• You can disable programming again by entering any number
(other than the access code) in this parameter.
• The E+H service organisation can be of assistance if you mislay
your personal code.
• The entry made here does not affect the local display. Therefore
programming via the function matrix must be enabled separately.
Displays the current status of access to the manufacturer-specific
parameters of the device.
Display:
• LOCKED (parameters cannot be modified)
• ACCESS CUSTOMER (parameters can be modified)
Entry of a personal code with which the configuration can be
enabled. This applies both to manufacturer-specific parameters in
the Transducer Blocks and also to operation via local display.
User input:
0...9999 (max. 4-digit number)
Factory setting:
93


Note!
• Programming is always enabled with the code "0".
• Configuration has to be enabled before this code can be
changed.
129
