Endress+Hauser PROline Prosonic Flow 93 Function Manual page 172

4 Analog Input function block
172
Base index: AI 1 = 350, AI 2 = 390, AI 3 = 430, AI 4 = 470, AI 5 = 510, AI 6 = 550, AI 7 = 590, AI 8 = 630
Parameter Write access
with operating
mode
(MODE_BLK)
HI_ALM AUTO - MAN -
OOS
HI_HI_ALM AUTO - MAN -
OOS
HI_HI_LIM AUTO - MAN -
OOS
HI_HI_PRI AUTO - MAN -
OOS
PROline Prosonic Flow 93 FOUNDATION Fieldbus
Analog Input function block /
Description
Alarm status display for the upper warning limit value, (HI_LIM),
including details of the time of the alarm (date, time) and the value
that triggered the alarm.


Note!
• In addition, the active alarm can be acknowledged in this
parameter group.
• If the option of the alarm has not been enabled in the
ACK_OPTION parameter, the alarm can only be acknowledged
via this parameter.
Alarm status display for the upper alarm limit value, (HI_HI_LIM),
including details of the time of the alarm (date, time) and the value
that triggered the alarm.


Note!
• In addition, the active alarm can be acknowledged in this
parameter group.
• If the option of the alarm has not been enabled in the
ACK_OPTION parameter, the alarm can only be acknowledged
via this parameter.
Entry of the alarm limit value for the upper alarm, (HI_HI_ALM). If
the output value OUT exceeds this limit value then the alarm status
parameter HI_HI_ALM is output.
User input:
Range and unit of OUT_SCALE
Factory setting:
38
3402823466 x 10
Specifies the action taken when the upper alarm limit value
(HI_HI_LIM) is exceeded.
User input:
0
The violation of the upper alarm limit is not evaluated.
1
No notification if the upper alarm limit is violated.
2
Reserved for block alarms.
3-7
The violation of the upper alarm limit is output as a user notice with
the appropriate priority (3 = low priority, 7 = high priority).
8-15
The violation of the upper alarm limit is output as a critical alarm
with the appropriate priority (8 = low priority, 15 = high priority).
Factory setting:
0
