Endress+Hauser PROline Prosonic Flow 93 Function Manual page 215

PROline Prosonic Flow 93 FOUNDATION Fieldbus
Endress+Hauser
PID function block (PID controller) / base index 810
Parameter Write access
with operating
mode
(MODE_BLK)
SP_HI_LIM ROUT - RCAS -
CAS - AUTO -
MAN - OOS
SP_LO_LIM ROUT - RCAS -
CAS - AUTO -
MAN - OOS
SP_RATE_DN ROUT - RCAS -
CAS - AUTO -
MAN - OOS
SP_RATE_UP ROUT - RCAS -
CAS - AUTO -
MAN - OOS
ST_REV read only
6 PID function block (PID controller)
Description
Entry of the upper limit of the setpoint value (reference value).
User input:
Range and unit of PV_SCALE ±10%
Factory setting:
100


Note!
If the setting for the end of the scale is changed in the PV_SCALE
parameter this value should be modified accordingly.
Entry of the lower limit of the setpoint value (reference value).
User input:
Value and range of PV_SCALE ±10%
Factory setting:
100


Note!
If the setting for the end of the scale is changed in the PV_SCALE
parameter this value should be modified accordingly.
Entry of the ramping rate of a diminishing setpoint value in the
AUTO operating mode.
Factory setting:
38
3402823466 x 10 PV per second


Note!
• If the value "0" is entered then this parameter is deactivated
and the setpoint value is used directly.
• The speed restriction is only active in the AUTO operating
mode.
Entry of the ramping rate of an increasing setpoint value in the
AUTO operating mode.
Factory setting:
38
3402823466 x 10 PV per second


Note!
• If the value "0" is entered then this parameter is deactivated
and the setpoint value is used directly.
• The speed restriction is only active in the AUTO operating
mode.
Displays the revision status of the static data.


Note!
The revision status parameter is incremented on each
modification of static data.
215
