Endress+Hauser PROline Prosonic Flow 93 Function Manual page 119

PROline Prosonic Flow 93 FOUNDATION Fieldbus
Endress+Hauser
"TRANSDUCER_CH1" and "TRANSDUCER_CH2" (E+H parameters) /
Parameter Write access
with operating
mode
(MODE_BLK)
Pipe Data - read only
Unit Pipe
Diameter
Pipe Data - AUTO - OOS
Wall Thickness
Pipe Data - read only
Unit Wall
Thickness
Pipe Data - AUTO - OOS
Liner Material
Pipe Data - AUTO - OOS
Sound Velocity
Liner
3 Transducer Blocks (transmission blocks)
Base index 1200 and 1300
Description
Displays the unit for the pipe circumference.


Note!
The unit is selected in the "System Unit - Length" parameter, see
Page 112.
Entry of the pipe wall thickness.
Measuring the wall thickness
Measurement can be carried out via:
• The local display ("Sensor" Quick Setup), see Page 19.
• The configuration and service software FieldTool.
User input:
Fixed-point number 0.1...100.0 (mm)
Factory setting:
3.2 (mm)


Note!
The unit used is displayed in the "Pipe Data - Unit Wall Thickness"
parameter.
Displays the unit for the thickness of the pipe wall.


Note!
The unit is selected in the "System Unit - Length" parameter, see
Page 112.
For selecting the material with which the pipe is lined.
Options:
LINER NONE
MORTAR
RUBBER
TAR EPOXY
OTHERS
Factory setting:
LINER NONE


Note!
This parameter is not active unless a liner was selected in the
"Pipe Data - Liner Material" parameter.
Entry of the sound velocity of the liner.
User input:
Fixed-point number 800...6500
Factory setting:
Depends on the setting selected in the "Pipe Data - Liner Material"
parameter.


Note!
The unit used is displayed in the "Pipe Data - Unit Sound Velocity
Liner" parameter.
119
