Endress+Hauser PROline Prosonic Flow 93 Function Manual page 189

PROline Prosonic Flow 93 FOUNDATION Fieldbus
Endress+Hauser
Discrete Output function block / base index 780
Parameter Write access
with operating
mode
(MODE_BLK)
SIMULATE_D AUTO - MAN -
OOS - CAS -
RCAS
SP_D AUTO - MAN -
OOS
ST_REV read only
STATUS_ OOS
OPTS
5 Discrete Output function block
Description
Simulation of the value and status of the process variable PV_D.
Factory setting:
Simulation Disabled (simulation not active)


Note!
• During the simulation, the value of OUT_D is not passed on to
the Transducer Block. The Transducer Block keeps the last
valid value from before the simulation was activated.
• The BLOCK_ERROR parameter of the Resource Block
indicates whether simulation is possible.
Entry of the discrete setpoint value.
Options:
0 = Starting point, no effect
1 = Reserved
2 = Positive zero return channel 1 "ON"
3 = Positive zero return channel 1 "OFF"
4 = Zero point adjustment channel 1
5 = Reserved
6 = Reserved
7 = Reset totalizers 1, 2, 3
8 = Reset totalizer 1
9 = Reset totalizer 2
10 = Reset totalizer 3
11 = Reserved
12 = Reserved
13 = Reserved
14 = Reserved
15 = Reserved
16 = Positive zero return channel 2 "ON"
17 = Positive zero return channel 2 "OFF"
18 = Zero point adjustment channel 2
Displays the revision status of the static data.


Note!
The revision status parameter is incremented on each
modification of static data.
Selects the available status options for specifying the status
processing and processing of the output value OUT_D.
The following options are supported:
Options:
Propagate Fault Backward
Pass on fault operation to upstream blocks.
Factory setting:
No option active
189
