PROline Prosonic Flow 93 FOUNDATION Fieldbus
Endress+Hauser
2.5

Resource Block parameters

The following table lists both the FOUNDATION Fieldbus parameters and the
Endress+Hauser-specific parameters, (from Page 99), of the Resource Block:
Parameter Write access with
operating mode
(MODE_BLK)
FOUNDATION Fieldbus parameters
ACK_OPTION AUTO - OOS
ALARM_SUM AUTO - OOS
ALERT_KEY AUTO - OOS
BLOCK_ALM AUTO - OOS
Resource Block / base index 258
Description
This parameter is used to specify whether a process alarm must be
acknowledged at the time of alarm detection by the fieldbus host
system. If this option is enabled the process alarm is
acknowledged automatically.
Options:
DISC ALM
Write protection no longer exists and thus the data can be
accessed.
BLOCK ALM
Block alarm
Factory setting:
The option is not enabled for any alarm, the alarms must be
acknowledged.
Displays the current status of the process alarms in the Resource
Block.
Display:
DISC ALM
Write protection no longer exists and thus the data can be
accessed.
BLOCK ALM
Block alarm


Note!
In addition, the process alarms can also be disabled in this
parameter group.
Entry of the identification number of the plant unit.
This information can be used by the fieldbus host system for sorting
alarms and events.
User input:
1...255
Factory setting:
0
Displays the current block status with information on pending
configuration, hardware or system errors, including details of the
alarm time (date, time) when the error occurred.
The block alarm is triggered in the event of the following block
errors:
• SIMULATION ACTIVE
• OUT OF SERVICE


Note!
If the option of the alarm has not been enabled in the
ACK_OPTION parameter, the alarm can only be acknowledged via
this parameter.
2 Resource Block
91
