3 Transducer Blocks (transmission blocks)
128
"TRANSDUCER_CH1" and "TRANSDUCER_CH2" (E+H parameters) /
Parameter Write access
with operating
mode
(MODE_BLK)
Simulation - AUTO - OOS
Measurand
Simulation - AUTO - OOS
Value Measurand
Simulation - Unit read only
Amp. Device read only
Family
PROline Prosonic Flow 93 FOUNDATION Fieldbus
Base index 1200 and 1300
Description
For activating the simulation for the volume flow.
Options:
OFF
VOLUME FLOW
Factory setting:
OFF


Caution!
• The measuring device cannot be used for measuring while this
simulation is in progress.
• The simulation functions independently of the position of the
relevant jumpers on the I/O board, (see Operating Instructions
for PROline Prosonic Flow 93 FOUNDATION Fieldbus,
BA078D/06/en, Section 5.4).
• The setting is not saved if the power supply fails.


Note!
Active simulation is relayed to downstream function blocks or
higher-level process control systems by means of the status
"UNCERTAIN" for the output value OUT (AI Block).
This parameter can be used to specify a selectable value (e.g.
3
12 m /s). This is used to test the assigned parameters in the
flowmeter itself and downstream function blocks.
User input:
5-digit floating-point number
Factory setting:
0


Note!
The unit used is displayed in the "Simulation - Unit" parameter.


Caution!
The setting is not saved if the power supply fails.
Displays the unit used in the "Simulation - Value Measurand"
parameter.


Note!
The unit is taken from the "System Unit - Volume Flow" parameter,
(see Page 110).
This parameter is only used in the event of servicing.
