6 PID function block (PID controller)
214
PID function block (PID controller) / base index 810
Parameter Write access
with operating
mode
(MODE_BLK)
ROUT_IN ROUT - RCAS -
CAS - AUTO -
MAN - OOS
ROUT_OUT read only
SHED_OPT
SP AUTO - MAN -
OOS
PROline Prosonic Flow 93 FOUNDATION Fieldbus
Description
In this parameter, the manipulated variable (value and status)
provided by the fieldbus host system is read in and displayed.


Note!
• Value statement and unit of OUT_SCALE
• This parameter is only active in the ROUT operating mode.
• The PID algorithm is no longer executed.
Displays the analog output value and status of the manipulated
variable transferred to the fieldbus host system in the course of
cascade control. The cascade control is initialised with this value
to ensure bumpless switching of the operating mode.


Note!
• Value statement and unit of OUT_SCALE
• This parameter is only active in the ROUT operating mode.
Selects the action taken if the monitoring time is exceeded (see
SHED_RCAS, SHED_ROUT parameters on Page 96) in the RCAS
or ROUT operating mode.
During the monitoring time, parameter updating between the
fieldbus host system and the PID function block is checked.
If the parameters are not being updated then on expiry of the
monitoring time the PID function block switches from the RCAS or
ROUT operating mode to the mode selected here.
Options:
Uninitialized
NormalShed_NormalReturn
NormalShed_NoReturn
ShedToAuto_NormalReturn
ShedToAuto_NoReturn
ShedToManual_NormalReturn
ShedToManual_NoReturn
ShedToRetainedTarget_NormalReturn
ShedToRetainedTarget_NoReturn
Factory setting:
Uninitialized
Entry of the setpoint value (reference value).
User input:
Range and unit of PV_SCALE ±10%


Note!
If the setting for the end of the scale is changed in the PV_SCALE
parameter this value should be modified accordingly.
