PROline Prosonic Flow 93 FOUNDATION Fieldbus
Endress+Hauser
"TRANSDUCER_DISP" (E+H parameters) / base index 1500
Parameter Write access
with operating
mode
(MODE_BLK)
Info Line AUTO - OOS
Multiplex -
Assign
3 Transducer Blocks (transmission blocks)
Description
Use this parameter to define the second reading to be displayed in
the information line alternately (every 10 seconds) with the value
defined in the "Info. Line - Assign" parameter.
Options:
OFF
VOLUME FLOW CH1
VOLUME FLOW CH2
CALC. VOLUME FLOW
VOLUME FLOW % CH1
VOLUME FLOW % CH2
CALC. VOLUME FLOW %
SOUND VELOCITY CH1
SOUND VELOCITY CH2
SOUND VELOCITY AVG.
SIGNAL STRENGTH CH1
SIGNAL STRENGTH CH2
FLOW VELOCITY CH1
FLOW VELOCITY CH2
FLOW VELOCITY AVG.
VOLUME FLOW BARGRAPH % CH1
VOLUME FLOW BARGRAPH % CH2
CALC. VOLUME FLOW BARGRAPH %
SIGNAL BARGRAPH CH1
SIGNAL BARGRAPH CH2
TOTALIZER 1
TOTALIZER 2
TOTALIZER 3
OPERATING/SYSTEM CONDITIONS
FLOW DIRECTION CH1
FLOW DIRECTION CH2
CALC. FLOW DIRECTION
AI 1 - OUT VALUE
AI 2 - OUT VALUE
AI 3 - OUT VALUE
AI 4 - OUT VALUE
AI 5 - OUT VALUE
AI 6 - OUT VALUE
AI 7 - OUT VALUE
AI 8 - OUT VALUE
PID - IN VALUE (controlled variable)
PID - CAS IN VALUE (remote setpoint value)
PID - OUT VALUE (manipulated variable)
DEVICE PD-TAG (tag name)
Factory setting:
OFF


Note!
Multiplex mode is suspended as soon as a fault/notice message is
generated. The appropriate error message appears on the display:
• Fault message (identified by a lightning icon):
Multiplex mode is resumed as soon as the fault is no longer active.
• Notice message (identified by an exclamation mark):
Multiplex mode is resumed as soon as the notice message is no
longer active.
