3 Transducer Blocks (transmission blocks)
134
"TRANSDUCER_DISP" (E+H parameters) / base index 1500
Parameter Write access
with operating
mode
(MODE_BLK)
Main Line AUTO - OOS
Multiplex -
Assign
Main Line AUTO - OOS
Multiplex -
100%-Value
PROline Prosonic Flow 93 FOUNDATION Fieldbus
Description
Use this parameter to define the second reading to be displayed in
the main line alternately (every 10 seconds) with the value defined in
the "User Interface Main Line - Assign" parameter.
Options:
OFF
VOLUME FLOW CH1
VOLUME FLOW CH2
CALC. VOLUME FLOW
VOLUME FLOW % CH1
VOLUME FLOW % CH2
CALC. VOLUME FLOW %
SOUND VELOCITY CH1
SOUND VELOCITY CH2
SOUND VELOCITY AVG.
SIGNAL STRENGTH CH1
SIGNAL STRENGTH CH2
FLOW VELOCITY CH1
FLOW VELOCITY CH2
FLOW VELOCITY AVG.
TOTALIZER 1
TOTALIZER 2
TOTALIZER 3
AI 1 - OUT VALUE
AI 2 - OUT VALUE
AI 3 - OUT VALUE
AI 4 - OUT VALUE
AI 5 - OUT VALUE
AI 6 - OUT VALUE
AI 7 - OUT VALUE
AI 8 - OUT VALUE
PID - IN VALUE (controlled variable)
PID - CAS IN VALUE (remote setpoint value)
PID - OUT VALUE (manipulated variable)
Factory setting:
OFF


Note!
The input is not active unless one of the following was selected in the
"Main - Multiplex Line Assign" parameter:
• VOLUME FLOW % CH1
• VOLUME FLOW % CH2
• CALC. VOLUME FLOW %
Use this parameter to define the flow value to be shown on the
display as the 100% value.
User input:
5-digit floating-point number
Factory setting:
Depends on country, [value] / [dm³...m³ or US-gal...US-Mgal]


Note!
The unit is taken from the "System Unit - Volume Flow" parameter,
(see Page 110).
