FC 300 Design Guide
Voltage level, logic '1' NPN (GND = 24 V)
Maximum voltage on input
Pulse frequency range
Duty cycle, min. pulse width
Input impedance
Analog inputs - Terminal X30/11, 12:
Analog input:
Number of analog inputs
Terminal number
Modes
Voltage level
Input impedance
Max. voltage
Resolution for analog inputs
Accuracy of analog inputs
Bandwidth
Digital outputs - Terminal X30/6, 7:
Digital output:
Number of digital outputs
Terminal number
Voltage level at digital/frequency output
Max. output current
Max. load
Max. capacitive load
Minimum output frequency
Maximum output frequency
Accuracy of frequency output
Analog output - Terminal X30/8:
Analog output:
Number of analog outputs
Terminal number
Current range at analog output
Max. load GND - analog output
Accuracy on analog output
Resolution on analog output

Encoder Option MCB 102

The encoder module can be used as feedback source for closed loop Flux control (par. 1-02) as well as
closed loop speed control (par. 7-00). Configure encoder option in parameter group 17-xx
Used for:
• VVC plus closed loop
• Flux Vector Speed control
• Flux Vector Torque control
• Permanent magnet motor
Supported encoder types:
Incremental encoder: 5 V TTL type, RS422, max. frequency: 410 kHz
Incremental encoder: 1Vpp, sine-cosine
Hiperface® Encoder: Absolute and Sine-Cosine (Stegmann/SICK)
EnDat encoder: Absolute and Sine-Cosine (Heidenhain) Supports version 2.1
Options and Accessories
MG.33.B8.02 - VLT ® is a registered Danfoss trademark
> 19 V DC
28 V continous
0 - 110 kHz
X30.11, X30.12
> 10 kΩ
10 bit (+ sign)
Max. error 0.5% of full scale
FC 301: 20 Hz/ FC 302: 100 Hz
X30.6, X30.7
≥ 600 Ω
≤ 32 kHz
Max. error: 0.1 % of full scale
0 - 20 mA
Max. error: 0.5 % of full scale
4.5 ms
> 2 kΩ
2
Voltage
0 - 10 V
20 V
2
0 - 24 V
40 mA
< 10 nF
0 Hz
1
X30.8
500 Ω
12 bit
