Parts for ZS3-ES Storage Appliance for Exalogic X5-2

Table D-3
Part
Number
F530-4436
F530-4437
F530-4438
F350-1519
F310-0307
F371-4784
F371-4785
F350-1521
F350-1546
D.4 Parts for ZS3-ES Storage Appliance for Exalogic X5-2
Table D-4
included in the Exalogic X5-2 machine:
Table D-4
Part Number
7015351
7020774
7018701
7097377
7066874
541-2732-03
7046442
7048710
D-4 Oracle Exalogic Elastic Cloud Machine Owner's Guide
(Cont.) Rack-Level Replacement Parts for EL X2-2 and X3-2
Description
CBL,7FT ETHERNET (CAT5/CAT5e),BLACK
CBL,10FT ETHERNET (CAT5/CAT5e),ORANGE
CBL,7FT ETHERNET (CAT5/CAT5e),ORANGE
ASSY,SERIAL CABLE SET(3) NM (2 Serial Cables + 1 Null
Modem)
ASSY,COOLING FAN FOR CISCO SWITCH
SNET,WS-C4948-S,CISCO CATALYST (Cisco Switch)
SPWR,PWR-C49-300AC,CISCO C4948 (Second Power Supply
for Cisco Switch)
BOLT-ON vented FILLER PNL,SUN RACKII,1U,VENT
1U CMA FOR QUICKSILVER,X4170
lists the replaceable parts for the ZS3-ES storage appliance, which is
Note:
All replacement parts shown in the following table are considered FRU when
covered under Premier Support of Systems warranty.

Replacement Parts for Oracle ZS3-ES Appliance

Description
CPU, INTEL, E5-2658, 2.1G, 95W, 8-core
ASSY, HEATSINK, CPU 1U Nashua, 60 MM Fin
LV DIMM, 16GB,DDR3,1 600, 1.3V
ASSY, SSD, 1.6TB, 2.5, SAS2,Readzilla
FRU, DR, 900GB, SAS2, 10K Marlin
ASSY, DVD FILLER W/USB, BZL, TRAY
DUAL PORT CX3 4XQDR PCI-E, LP
ASSY, RISER, X8, 1U, PCI-E
Coverage
under Basic
Warranty
FRU
FRU
FRU
FRU
FRU
FRU
FRU
FRU
FRU
Coverage under
Basic Warranty
FRU
FRU
FRU
FRU
FRU
FRU
FRU
FRU
