Using Monitoring Profiles and Rules
Expand Plan Management in the navigation pane.
1.
Click Monitoring Profiles.
2.
Click Create Profile in the Action pane.
3.
Provide a name and description for the monitoring profile, then select the
4.
resource type for the profile from the Subtype list.
Click Finish to save the profile. The new profile will appear in the center content
5.
pane.
(Optional) To add or remove rules or change monitoring parameters, double-click
6.
the profile in the center content pane.
(Optional) To make this profile the default monitoring profile, click the Set as
7.
Default Profile icon.

17.15.2 Adding a Monitoring Rule from the Asset View

To add a monitoring rule from the asset view, do the following:
Click Assets in the Navigation pane, expand the tree and click the asset to which
1.
you want to add the rule.
Click the Monitoring tab to see a list of all the monitoring rules.
2.
Click the Add Alert Monitoring Rule icon in the center pane. The Add Alert
3.
Monitoring Rule Parameters window is displayed.
Select a Rule Type from the drop-down menu: Threshold, Boolean Control,
4.
Enumerated Control or Expression
Select an Asset Type from the drop-down menu.
5.
Complete the Monitored Attribute. If you selected Expression, the Monitored
6.
Attribute option is not available.
Provide a name and description for the rule that will appear in the Profile Details
7.
page.
Define the monitoring schedule, either continuously or for a specific time period.
8.
The start and end times are based on the monitored asset's time zone.
Define how long the alerting condition must last to be considered an alert. The
9.
default setting is 5 minutes. You can change the amount of time and the unit of
measurement to be either minutes, hours, or days.
Complete the Alert parameters for the different severity levels.
10.
Use the Immediate Action field to define what action should take place when a
11.
problem is detected.
Click Apply to save the rule. The new rule will appear in the profile.
12.
17-30 Oracle Exalogic Elastic Cloud Machine Owner's Guide
