Table 2-2
Location
Rear maintenance
Front maintenance
Top maintenance

2.3 Flooring Requirements

Oracle recommends that the Exalogic machine be installed on raised flooring. The site
floor and the raised flooring must be able to support the total weight of the Exalogic
machine as specified in
Table 2-3
Table 2-3
Description
Maximum allowable weight of installed rack equipment
Maximum allowable weight of installed power distribution units
Maximum dynamic load (maximum allowable weight of installed
equipment including PDUs)

2.4 Electrical Power Requirements

Exalogic Machine can operate effectively over a wide range of voltages and
frequencies. However, it must have a reliable power source. Damage may occur if the
ranges are exceeded. Electrical disturbances such as the following may damage
Exalogic Machine:
• Fluctuations caused by brownouts
• Wide and rapid variations in input voltage levels or in input power frequency
• Electrical storms
• Faults in the distribution system, such as defective wiring
To protect your Exalogic machine from such disturbances, you should have a
dedicated power distribution system, power-conditioning equipment, as well as
lightning arresters or power cables to protect from electrical storms.
Each rack has two pre-installed power distribution units (PDUs). The PDUs accept
different power sources. You must specify the type of PDU that is correct for your data
center.

Maintenance Access Requirements for Exalogic Machine

Maintenance Access Requirement
914 mm (36 inches)
914 mm (36 inches)
914 mm (36 inches)
Environmental
lists the floor load requirements.

Floor Load Requirements for Exalogic Machine

Note:
Open tiles are required for electrical access.
Requirements.
Flooring Requirements
Requirement
952.54 kg (2100 lbs)
52.16 kg (115 lbs)
1004.71 kg (2215 lbs)
Site Requirements 2-3
