Go to Control Panel > Network Connections. Select your wired network
a.
adapter in the list of network connections, right-click and select
Properties. The network properties screen is displayed.
Click the General tab, and select Internet Protocol (TCP/IP). Click
b.
Properties. The Internet Protocol (TCP/IP) Properties screen is displayed.
Select the Use the following IP address: option, and enter a static IP
c.
address for your laptop. Although a default gateway is not necessary,
enter the same IP address in the Default Gateway field. Click OK to exit
the network connections screen.
Note:
This static IP should be on the same subnet and address range as the network
on which the Cisco Ethernet switch resides. You can use the default NET0 IP
addresses of compute nodes assigned at the time of manufacturing or the
custom IP address that you reconfigured using the Oracle Exalogic
Configuration Utility. For the list of default NET0 IP addresses, see
Default IP Addresses and
• If you are using a Linux operating system on your laptop, do the following:
Log in as a root user.
a.
At the command prompt, enter the following command to display the
b.
network devices, such as ETH0, attached to the Exalogic machine:
# ifconfig -a
The list of network devices or adapters attached to the Exalogic machine
is displayed.
To set up the desired network interface, run the ifconfig command at
c.
the command prompt, as in the following example:
# ifconfig eth0 192.168.1.150 netmask 255.255.255.0 up
In this example, the ifconfig command assigns the IPv4 address
192.168.1.150, with a network mask of 255.255.255.0, to the eth0
interface.
For laptop connectivity, open any telnet or ssh client program, such as PuTTY.
6.
Connect to one of the service processor IP addresses or to the IP address of a
compute node, which is up and running.
Connect a Laptop to the Exalogic Machine
Ports.
Install Planning and Procedure 3-19
