Oracle Exalogic Elastic Cloud Owner's Manual page 59

Table 4-2 (Cont.) Default ILOM, NET0, and IB Bonded IP for Exalogic Half Rack
Unit Rack Component (Front View)
25 Cisco Management Switch
24 1U Solid Filler
23 Sun Network QDR InfiniBand
Gateway Switch
22 Server head for the storage appliance 192.168.1.116
21 Server head for the storage appliance 192.168.1.115
20 Disk storage tray for the storage
appliance
19
18
17
16 Sun Network QDR InfiniBand
Gateway Switch
15 Compute Node
14 Compute Node
13 Compute Node
12 Compute Node
11 Compute Node
10 Compute Node
9 Compute Node
8 Compute Node
7 Compute Node
6 Compute Node
5 Compute Node
4 Compute Node
3 Compute Node
2 Compute Node
1 Sun Datacenter InfiniBand Switch 36
Exalogic Machine Half Rack
ILOM IP NET0 IP
Address Address
Not 192.168.1.200
applicable
Not Not
applicable applicable
192.168.1.202 Not
applicable
192.168.1.16
192.168.1.15
Not Not
applicable applicable
192.168.1.201 Not
applicable
192.168.1.114 192.168.1.14
192.168.1.113 192.168.1.13
192.168.1.112 192.168.1.12
192.168.1.111 192.168.1.11
192.168.1.110 192.168.1.10
192.168.1.109 192.168.1.9
192.168.1.108 192.168.1.8
192.168.1.107 192.168.1.7
192.168.1.106 192.168.1.6
192.168.1.105 192.168.1.5
192.168.1.104 192.168.1.4
192.168.1.103 192.168.1.3
192.168.1.102 192.168.1.2
192.168.1.101 192.168.1.1
192.168.1.205 Not
applicable
Default IP Addresses and Ports 4-5
IB Bonded IP
Address
Not
applicable
Not
applicable
Not
applicable
192.168.10.16
192.168.10.15
Not
applicable
Not
applicable
192.168.10.14
192.168.10.13
192.168.10.12
192.168.10.11
192.168.10.10
192.168.10.9
192.168.10.8
192.168.10.7
192.168.10.6
192.168.10.5
192.168.10.4
192.168.10.3
192.168.10.2
192.168.10.1
Not
applicable
