-W- Topology file is not specified.
Reports regarding cluster links will use direct routes.
Loading IBDM from: /usr/lib/ibdm1.2
-I- Using port 0 as the local port.
-I- Discovering ... 2 nodes (1 Switches & 1 CA-s) discovered.
.
.
.
-I- Links With links width != 4x (as set by -lw option)
-I---------------------------------------------------
-I- No unmatched Links (with width != 4x) were found
-I---------------------------------------------------
-I- Links With links speed != 10 (as set by -ls option)
-I---------------------------------------------------
-I- No unmatched Links (with speed != 10) were found
.
.
.
-I- Stages Status Report:
STAGE
Bad GUIDs/LIDs Check
Link State Active Check
Performance Counters Report
Specific Link Width Check
Specific Link Speed Check
Partitions Check
IPoIB Subnets Check
Please see /tmp/ibdiagnet.log for complete log
----------------------------------------------------------------
-I- Done. Run time was 1 seconds.

14.6.3 Check for Errors in the InfiniBand Fabric in a Multirack Configuration

Use the ibcheckerrors command that uses the topology file to scan the InfiniBand
fabric and validate the connectivity as described in the topology file, and to report
errors as indicated by the port counters.
On the command-line interface (CLI) of the spine switch, enter the following
command:
# ibcheckerrors
## Summary: 4 nodes checked, 0 bad nodes found
##
Errors Warnings
Note:
The actual output for your InfiniBand fabric will differ from that in the
example.
34 ports checked, 0 ports have errors beyond threshold
Note:
The actual output for your InfiniBand fabric will differ from that in the
example.
Use the Sun Datacenter InfiniBand Switch 36 in Multirack Configurations 14-7
Verify the InfiniBand Fabric in a Multirack Configuration
0 0
0 0
0 0
0 0
0 0
0 0
0 0
