Space Requirements

2.2.1 Receiving and Unpacking Requirements

Before your Exalogic machine arrives, ensure that the receiving area is large enough
for the package. The following are the package dimensions for the Exalogic machine:
• Shipping height: 2159 mm (85 inches)
• Shipping width: 1219 mm (48 inches)
• Shipping depth: 1575 mm (62 inches)
• For the shipping weight, see the data sheets at the following location:
http://www.oracle.com/technetwork/server-storage/engineered-
systems/exalogic/index.html
If your loading dock meets the height and ramp requirements for a standard freight
carrier truck, then you can use a pallet jack to unload the rack. If the loading dock does
not meet the requirements, then you must provide a standard forklift or other means
to unload the rack. You can also request that the rack be shipped in a truck with a lift
gate.
When the Exalogic machine arrives, leave the rack in its shipping packaging until it
arrives in its installation site. Use a conditioned space to remove the packaging
material to reduce particles before entering the data center. The entire access route to
the installation site should be free of raised-pattern flooring that can cause vibration.
Allow enough space for unpacking it from its shipping cartons. Ensure that there is
enough clearance and clear pathways for moving the Exalogic machine from the
unpacking location to the installation location.
requirements for the Exalogic machine.
Table 2-1
Access Route Item
Minimum door height
Minimum door width
Minimum elevator depth
Maximum incline
Minimum elevator, pallet jack,
and floor loading capacity

2.2.2 Maintenance Access Requirements

The maintenance area must be large enough for the Exalogic machine, and have the
required access space. For example, the required space to remove the side panels is
675. 64 mm (26.6 inches).
Exalogic machine.
2-2 Oracle Exalogic Elastic Cloud Machine Owner's Guide

Access Route Requirements

With Shipping Pallet
2184 mm (86 inches)
1220 (48 inches)
1575 mm (62 inches)
6 degrees
1134 kg (2500 lbs)
Table 2-2 lists the maintenance access requirements for the
Table 2-1 lists the access route
Without Shipping Pallet
2040 mm (80.32 inches)
600 mm (23.62 inches)
1200 mm (47.24 inches)
6 degrees
1134 kg (2500 lbs)
