Table E-5 (Cont.) InfiniBand Network Cabling for Exalogic Machine Full Rack
From Port
Rack Unit
(Sun
Network
QDR
InfiniBand
Gateway
Switch)
U16 10A
U16 10B
U16 11A
U16 11B
U16 12A
U16 12B
U16 13A
U16 13B
U16 14A
U16 14B
U16 15A
U16 15B
Table E-6 lists the InfiniBand gateway switch inter-connections for an Exalogic
machine full rack.
To Rack Type of
Unit Equipment
U13 Compute node
U12 Compute node
U11 Compute node
U10 Compute node
U9 Compute node
U8 Compute node
U7 Compute node
U6 Compute node
U5 Compute node
U4 Compute node
U3 Compute node
U2 Compute node
InfiniBand Network Cabling Tables
Port Description
PCIe 2, P2 2 meter QDR
InfiniBand cable
PCIe 2, P2 2 meter QDR
InfiniBand cable
PCIe 2, P2 2 meter QDR
InfiniBand cable
PCIe 2, P2 2 meter QDR
InfiniBand cable
PCIe 2, P1 2 meter QDR
InfiniBand cable
PCIe 2, P1 2 meter QDR
InfiniBand cable
PCIe 2, P1 3 meter QDR
InfiniBand cable
PCIe 2, P1 3 meter QDR
InfiniBand cable
PCIe 2, P1 3 meter QDR
InfiniBand cable
PCIe 2, P1 3 meter QDR
InfiniBand cable
PCIe 2, P1 3 meter QDR
InfiniBand cable
PCIe 2, P1 3 meter QDR
InfiniBand cable
