Set Up Ethernet Over InfiniBand (EoIB) on Oracle Linux
Create the interface file for the first VNIC, eth4 in the example, by using a text
13.
editor such as vi.
Save the file in the /etc/sysconfig/network-scripts directory.
Example:
# more /etc/sysconfig/network-scripts/ifcfg-eth331_1
DEVICE=eth331_1
BOOTPROTO=none
ONBOOT=yes
HWADDR=a2:c0:a0:a8:01:01
MASTER=bond1
SLAVE=yes
•
•
•
Create an interface file for the second VNIC, say eth5. Be sure to name the
14.
interface file and specify the DEVICE directive by using a derived interface name
and not the kernel-assigned name, as described earlier. In addition, be sure to
specify the relevant dummy MAC address for the HWADDR directive.
After creating the interface files, create the ifcfg-bond1 file. If the file already
15.
exists, verify its contents.
Example:
# more /etc/sysconfig/network-scripts/ifcfg-bond1
DEVICE=bond1
IPADDR=192.168.48.128
NETMASK=255.255.255.0
BOOTPROTO=none
USERCTL=no
TYPE=Ethernet
ONBOOT=yes
IPV6INIT=no
BONDING_OPTS="mode=active-backup miimon=100 downdelay=5000 updelay=5000"
GATEWAY=192.168.48.1
Bring up the new bond1 interface using the ifup command.
16.
You must also reboot the compute node for the changes to take effect.
10-6 Oracle Exalogic Elastic Cloud Machine Owner's Guide
Device name: ethA_B
A is the EPORT_ID, and B is the number after the colon (:) in the IOA_PORT
value.
Example:
Interface file name: ifcfg-eth331_1
Device name: eth331_1
In this example, 331 is the EPORT_ID, and 1 is the value derived from the
IOA_PORT.
Make sure that the name of the interface file (ifcfg-eth331_1 in the
example) is the name derived in step 12.
For the DEVICE directive, specify the device name (eth331_1 in the
example) derived in step 12.
For the HWADDR directive, specify the dummy MAC address created in step 5.
