-I- Links With links width != 4x (as set by -lw option)
-I---------------------------------------------------
-I- No unmatched Links (with width != 4x) were found
-I---------------------------------------------------
-I- Links With links speed != 10 (as set by -ls option)
-I---------------------------------------------------
-I- No unmatched Links (with speed != 10) were found
.
.
.
-I- Stages Status Report:
STAGE
Bad GUIDs/LIDs Check
Link State Active Check
Performance Counters Report
Specific Link Width Check
Specific Link Speed Check
Partitions Check
IPoIB Subnets Check
Please see /tmp/ibdiagnet.log for complete log
----------------------------------------------------------------
-I- Done. Run time was 1 seconds.
12.1.6.3 Validate and Check Errors in the InfiniBand Fabric
Use the ibcheckerrors command that uses the topology file to scan the InfiniBand
fabric and validate the connectivity as described in the topology file, and to report
errors as indicated by the port counters.
On the command-line interface (CLI), enter the following command:
# ibcheckerrors
## Summary: 4 nodes checked, 0 bad nodes found
##

12.1.7 Monitor a Gateway Switch Using Web Interface

Open a web browser and go to the following URL:
1.
http://gateway-IP
where gateway-IP is the IP address of a gateway switch.
Log in to the interface as the root user.
2.
Click the Switch/Fabric Monitoring Tools tab.
3.
Errors Warnings
Note:
The actual output for your InfiniBand fabric will differ from that in the
example.
34 ports checked, 0 ports have errors beyond threshold
Note:
The actual output for your InfiniBand fabric will differ from that in the
example.
Using Sun Network QDR InfiniBand Gateway Switches
0 0
0 0
0 0
0 0
0 0
0 0
0 0
Use the InfiniBand Gateway Switches 12-7
