Monitor the Spine Switch Using Web Interface

14.7 Monitor the Spine Switch Using Web Interface
Open a web browser and go to the following URL:
1.
http://switch-IP
where switch-IP is the IP address of the spine switch.
Log in to the interface as the root user.
2.
Click the Switch/Fabric Monitoring Tools tab.
3.
Click Launch Sun DCS GW Monitor.
4.
The Fabric Monitor is displayed.

14.8 What Next?

After setting up the Sun Datacenter InfiniBand Switch 36 in a multirack configuration
scenario, you can proceed to monitor and control the InfiniBand fabric.
14-8 Oracle Exalogic Elastic Cloud Machine Owner's Guide
