Power Distribution Unit Cabling Tables
Table E-20
From Rack
Unit
U25
U23
U22
U21
U17
U16
U09
U08
U07
U06
U05
U04
U03
U02
E.3.8 Three Phase PDU Power Cabling Eighth Rack
This section contains the following tables:
• Table E-21
Table E-21
an Exalogic machine eighth rack.
Table E-21
From Rack
Unit
U25
U23
U22
U21
U17
U16
E-30 Oracle Exalogic Elastic Cloud Machine Owner's Guide

Three Phase PDU Power Cabling for Exalogic Machine Quarter Rack

Type of Equipment
Cisco Switch
NM2-GW-SW
ZS3-ES HN
ZS3-ES HN
DE2-24C DS
NM2-GW-SW
Compute node
Compute node
Compute node
Compute node
Compute node
Compute node
Compute node
Compute node
lists the location, ports and cables for the Three Phase PDU connections for

Three Phase PDU Power Cabling for Exalogic Machine Eighth Rack

Type of Equipment
Cisco Switch
NM2-GW-SW
ZS3-ES HN
ZS3-ES HN
DE2-24C DS
NM2-GW-SW
PDU-A PDU-B
G3-1 G0-5
G2-5 G5-1
G3-0 G0-6
G2-4 G5-2
G2-3 G5-3
G1-6 G4-0
G1-1 G4-5
G1-0 G4-6
G0-6 G3-0
G0-5 G3-1
G0-4 G3-2
G0-3 G3-3
G0-2 G3-4
G0-1 G3-5
PDU-A PDU-B
G3-1 G0-5
G2-5 G5-1
G3-0 G0-6
G2-4 G5-2
G2-3 G5-3
G1-6 G4-0
Jumper Length
2M
2M
2M
2M
1M
2M
2M
2M
2M
2M
2M
2M
2M
2M
Jumper Length
2M
2M
2M
2M
1M
2M
