Table E-10 (Cont.) InfiniBand Network Cabling for Exalogic Machine Quarter Rack
From Port
Rack Unit
(Sun
Network
QDR
InfiniBand
Gateway
Switch)
U23 14B
U23 15A
U23 15B
U16 8A
U16 8B
U16 12A
U16 12B
U16 13A
U16 13B
U16 14A
U16 14B
U16 15A
U16 15B
Table E-11 lists the InfiniBand gateway switch inter-connections for an Exalogic
machine quarter rack.
To Rack Type of
Unit Equipment
U4 Compute node
U3 Compute node
U2 Compute node
U22 Storage appliance
server head
U21 Storage appliance
server head
U9 Compute node
U8 Compute node
U7 Compute node
U6 Compute node
U5 Compute node
U4 Compute node
U3 Compute node
U2 Compute node
InfiniBand Network Cabling Tables
Port Description
PCIe 2, P2 3 meter QDR
InfiniBand cable
PCIe 2, P2 3 meter QDR
InfiniBand cable
PCIe 2, P2 3 meter QDR
InfiniBand cable
PCIe 0, P1 3 meter QDR
InfiniBand cable
PCIe 0, P1 3 meter QDR
InfiniBand cable
PCIe 2, P1 2 meter QDR
InfiniBand cable
PCIe 2, P1 2 meter QDR
InfiniBand cable
PCIe 2, P1 2 meter QDR
InfiniBand cable
PCIe 2, P1 3 meter QDR
InfiniBand cable
PCIe 2, P1 3 meter QDR
InfiniBand cable
PCIe 2, P1 3 meter QDR
InfiniBand cable
PCIe 2, P1 3 meter QDR
InfiniBand cable
PCIe 2, P1 3 meter QDR
InfiniBand cable
