Reracking Checklists

B.10 Reracking Checklists
Reracking of Exalogic half racks, Exalogic quarter racks, or Exalogic eighth racks is
allowed when the customer site requires a specialized infrastructure. Exalogic full
racks cannot be reracked due to potential air flow and cooling issues.
Complete the following checklist prior to reracking an Exalogic machine:
Reracking Considerations
Has the customer purchased Oracle
Reracking Service?
Has the customer purchased the
Oracle Installation Service?
Is there a cart capable of carrying the
weight of the servers to move the
components and associated cabling
from the supplied rack to the
customer supplied rack?
Do the target rack dimensions meet
the following requirements?
• Height: 42RU (shorter racks can
be supported with customer
provided PDUs)
• Width: 600mm
• Depth: 1112mm without front
and rear doors
Is the target rack at least 30 RU tall
and does it include the customer
provided PDUs?
If the rack is less than 42 RU, then the
rack must be at least 30 RU tall and
the customer must provide
compatible PDUs to install in the
target rack.
Is the distance between the front and
rear mounting planes between the
minimum of 610 mm and the
maximum 915 mm (24 inches to 36
inches)?
B-10 Oracle Exalogic Elastic Cloud Machine Owner's Guide
Note:
• Customer must purchase both the Oracle Reracking Service and Oracle
Installation Service.
• Oracle does not provide support for customer-supplied equipment.
Yes No N/A Comment
